Raypak 266 Digital Cupro Nickel Pool Heater, 6000-9000 ft.

#014947 Raypak 266 Digital, HD Cupro-Nickel, Pool and Spa Heater, Natural Gas, High Elevation: 6000-9000 (feet)

Free Shipping!
Not for use in parts of California!
Available Models:
Raypak Part #014947
Raypak Model #P-R266A-EN-X #53
Rheem Part #014975
Rheem Model #P-M266A-EN-X #53
Ruud    Part #015003
Ruud    Model #P-D266A-EN-X #53
Cupro-nickel's major advantage over standard copper is that it's more tolerant of bad water chemistry and is more resistant to erosion thanks to a harder surface and a wall that is approximately 50% thicker. When you are unsure of your ability to maintain the pool or spa water chemistry a cupro-nickel heat exchanger is a cost-effective way to protect against premature failure.

PolyTuf Textured Powder Coating
The Raypak 266 Digital Cupro-Nickel High Altitude gas heater has a polyester-coated, non-corrosive cabinet that is more durable than solventborne- and waterborne-coated metal cabinets. Every piece of sheet metal goes through a 7-stage wash system, making certain the powder paint has a perfect bond. Underneath the tough, yet beautiful finish you will find galvanized metal that offers superior rust prevention and years of durable service.

Wind-Resistant Design
No need for fans to combat drafting problems under normal conditions. This heater is designed to draft naturally in outdoor installations with its exclusive low-profile design. It is so thoughtfully and carefully designed, it actually protects itself from the things that tend to stifle ordinary pool and spa heaters. It delivers uninterrupted heating performance regardless of falling leaves, wind, airborne debris, rain, downdrafts, updrafts, sleet, snow, etc.

Polymer Headers
Polymer headers prevent rust stains from harming your pool’s surface, giving you years of trouble-free swimming pleasure.

Cupro Nickel Tube Heat Exchanger

Stainless Steel Tube Sheet
Stainless steel tube sheets are used on all Raypak heaters with the polymer headers. This allows for a completely nonferrous waterway, leaving your pool truly rust-free.

CPVC 2" Water Connections
Standard with every Raypak 266 Digital Cupro-Nickel High Altitude is a set of 2" slip-fit CPVC water connections to make your installation secure and effortless.

Condensation Protection
The Unitherm Governor inside the header helps reduce condensation from low inlet water temperatures. It automatically regulates the water flow to help keep the water temperature in the heat exchanger above 105°F. Both water temperature and water flow rate are controlled to eliminate condensation, sooting, and scale build-up that can shorten heater life.

High Flow Rates
The Raypak 266 Digital Cupro-Nickel High Altitude gas heater comes with an automatic bypass built into the header. You'll find that the heater is capable of handling water flow at a rate up to 125 GPM.

Burner Tray
Every burner tray is built to last, from the stainless steel burners to the aluminized metal used in the heat sensitive areas. Innovative design allows for the easy removal of the tray and burners for servicing.

Fire Tile
A ceramic fiber combustion box keeps your heater running efficiently while keeping the outside jacket cool. By using this space-age material the heater won't retain residual heat after it is turned off, allowing it to be installed without the use of costly metal heat sinks.

Fuel-Efficient
Energy-smart Raypak 266 heaters consistently achieve the highest efficiency ratings. They exceed all federal and state standards.

www.raypak.com
Raypak Digital Pool & Spa Heaters Brochure
